Jump Kit

The Framework for Civil 3D



Framework for Civil 3D Release 8 products support Autodesk Civil 3D 2023

Framework for Civil 3D Release 8 products support Autodesk Civil 3D 2022.1
Framework for Civil 3D Release 8 products support Autodesk Civil 3D 2021.3
Framework for Civil 3D Release 8 products support Autodesk Civil 3D 2020.6.1

Framework for Civil 3D Release 8 products support Civil 3D 2023-2019

Jump Kit Release 8 is available for Civil 3D 2023-2019
Jump Kit Release 8 AIA is available for Civil 3D 2023-2020

Jump Kit Pricing

See the Overview Videos for a visual review of the Framework for Civil 3D

Jump Kit is our most popular Framework for Civil 3D product

The Jump Kit Civil 3D Style library is an easy to use integrated collection of resource drawings and support files built ByDesign to help manage, implement, and maintain Civil 3D in production.

The Jump Kit  includes all of the InstantOn Desktop, the Symbol Set libraries, and vast Style libraries.

• Customize Civil 3D FAST
• The Framework Spreadsheet Tools make Customization Easy
• Add Styles from the 1000's of Styles in the libraries
• Easily create custom Production and Publication templates
• Built in support for Reference Templates (TREF)
• Default resources now available in either or both NCS 6.0 and AIA NCS 6.0 utility layer schemes

Adaptive Building Block Technology

Easy to Assemble Custom Style Tools for Better Production Templates for Civil 3D

See the Release 8 Details for the latest details.

• Build Task-based Templates for Civil 3D Faster
• Complete Common Specialty Style Collections of Civil Engineered Structures
• In-depth Description Key Set resources with integrated Figure Prefix Db support
• In-depth Civil 3D Feature Line, Parcel, Alignment, and Section Styles for each Collection
• Separate collections of detailed Profile View and Section View Styles
• Separate collections of infrastructure utility system Style Tools
• Built-in resource support for the Civil 3D Reference Template (TREF) Tool

Adaptive Layer Standards Support

See the Release 8 Details for the latest details.

• Includes all the tools and resources for Layer Standards construction and maintenance
• Fully-integrated Layer State management tools and script generation
• Allows for more flexible project publication with less hassle
• NCS 6.0 and/or Classic AIA Utilities
• Older NCS 5.0 and/or Classic AIA Utilities are supported
• Integrated in-depth standards support for GSA, DOD, US Army Corps, and related variants
• Build, manage, and maintain Custom Key-based Layer schemes on demand

Jump Kit Library Highlights

See the Release 8 Details for the latest details.

• Powerful new Label Style Expression Set Style collections
• An Adaptive Template Block library
• All Styles support both STB and CTB
• Hundreds of variations of Description Key Sets
• Hundreds of variations of Profile Views Styles
• Hundreds of variations of Section Views Styles
• Expanded Pipes and Pressure Pipe and Conduit systems Styles
• Hundreds of variations of critical Label Styles for every Civil 3D Feature
• Prototype Label Styles with advanced Expressions
• Point Styles with variations of Symbols in Object and View configurations
• Annotative Alignment Label Styles for typical Plan features
• Property and Bondaries
• Site Features
• Utilities
• Prebuilt Style Collections for Utility Pipe and Pressures Networks
• and More

Currently,
Jump Kit does not include custom Civil 3D catalogs.
All resources are supplied in US Imperial Units and can be converted to metric.

Jump Kit includes:

• InstantOn
• Symbol Set
• Blocks Only

The Jump Kit is a per user licensed product.
The product is sold in an initial 5 seat block.
6 and more Civil 3D seats in use require additional licenses.
